FILPA TK3 - fuel tanker
FILPA 3 AXLES FUEL TANKER SEMI TRAILER
Chassis Construction
Chassis and other metal pieces are made of high – strength steel (S500MC) with special automatic Co2 argon welding machine.
Tank Construction
Made of 4mm ST37steel sheet with 3 separate reservoirs/ sealed and seamless tanker body welding with automatic welding machines along with welding quality tests
Braking System
EBS System (Electrical Anti Block Brake System) with RSP (Roll Stability Program) Disc and Drum, Knorr® / Wabco®(germany) Two double acting diaphragm brake chamber per axle.
Suspension and axles
3×9 ton EU standard disc brake or drum brake, front lift axle
Painting
Shot blasted, according to SA2/5 and washed by special material, painted with a layer of epoxy primer and of polyurethane final coat
Electric System
7 and 15 Pole quick release connector, Austrian Pair of 24 volts rear light, side light and alarming system from Aspock with LED Type.
Axle/ Suspension
axle with air bags cylinder air suspension system with special shock absorber Lower and Rise Capability of Trailer
Landing Legs
Static Capacity 50 Tons & Dynamic Capacity 24 Tons (JOST) Germany
King pin
2 Inch JOST king pin made in Germany
Tires
6 pieces 385/65R22.5
Rim
6 pieces rims 22.5 × 11.75 tubless
Valves
Charge and discharge valves according to National Iranian Gas Company
Trailer park lock system
Automatic front lift axle
60 Lit Water tank
Holder for fire extinguisher
Fix Rear bumper
Toolbox
Spare tire holder
Valve box
Plastic chock
6 pcs mud guards and 2 mud flaps
Walkway covered with aluminum
anti-slip plate
Holding standard and certificate of welding inspection and dimensional control and hydrostatic test
Optional rims and spare Tires
Loading and unloading system control kit and emergency disconnection system
King pin load
11500 kg
Centre of rear axle to rear edge of body
1440 mm
Axle load
27000 kg
Outside width
2550 mm
Tare weight
7900 kg
Overall height
3200mm
Pay load
33000 kg
Overall length
10950mm
5th wheel
1150 - 1200 mm
Body volume
33000 LITTRE
Truck type
Designed for 6 wheels Trucks
Chassis material
S500
Axle spread
1310 mm
Body shape
"Elliptical"
Wheelbase
6860 mm
Body material
4mm St37
Rear overhang
2750mm
Body length
10450mm
